MODEL |
UNIT |
CM-565
|
CM-1065
|
X axis travel |
mm(in) |
550(19 11/16) |
1000(39) |
Y axis travel |
mm(in) |
600(23 5/8) |
600(23 5/8) |
Z axis travel |
mm(in) |
500(19 11/16) |
500(19 1/2) |
Distance between working table & spindle nose |
mm(in) |
150~650(5 7/8"x 25 2/5")
|
Table Dimension (X*Y) |
mm(in) |
700x600(27 1/2" x 23 5/8) |
1200x600(47 1/4" x 23 5/8) |
T slot? W1xH1xW2xH2 |
mm(in) |
30 x 12 x 18 |
Taper of spindle nose |
|
|
Spindle speeds |
r.p.m |
10000 |
Maximum Tool Diameter |
mm(in) |
70(2 3/4)
|
Maximum Tool Weight |
kg |
6 |
Maximum Weight for workpiece |
kg |
800 |
800 |
Spindle motor |
kw/HP |
5.5/7.5(7.3/10) |
Cutting feed rate |
mm/min
(in/min) |
1~10000(1~393) |
RAPID FEEDRATE(X-Y-Z) |
m/min. |
X,Y24, OP(36) / Z 15, OP(24) |
No. of Tools (ATC) |
pcs |
16/24 |
| X/Y/Z SERVO MOTOR |
kw |
2/2/2 |
Air source |
kg/cm2 |
7(100) |
Machine dimension (WxDxH) |
mm(in) |
2500 x 2100 x 2700
(94 1/8" x 83 x 106 1/2") |
2800 x 2400 x 3100
(110 3/16 x 94 7/16 x 122) |
Machine weight |
≒kgs
(lbs) |
≒6700(12335) |
≒8800(16500) |
Controller |
|
Simens/Hedenhain/Mitsubishi/Fanuc/SELCA/PC-BASED |
*All specifications and design are subject to change without prior notice. |
