| ITEM |
UNIT |
CNC-
326 |
CNC-
408 |
CNC-
462 |
CNC-
640 |
CNC-
860 |
CNC-
1080 |
CNC-
1280 |
Work
tank volume
(W x D x H) |
mm
(in) |
750
x 480 x300
(29 1/2 x 18 7/8 x11 13/16) |
1000
x 600 x415 (39-3/8x23-5/8x16-
5/16) |
850
x 600 x 300
( 33 7/16 x 23 5/8 x 11 13/16) |
1300
x750 x520
(51 x29-1/2 x 20 1/2) |
2000
x1000 x600
(78-3/4 x39-3/8 x23-5/8) |
1200 x2000 x550
(47-1/4 x78-3/4 x21-5/8) |
1400
x2000 x600
(55-1/8 x78-3/4 x23-5/8) |
| Max.
workpiece weight |
kgs
(lbs) |
500
(1100) |
500
(1100) |
1000
(2200) |
2200(4850) |
4500
(9900) |
7000(fluid
immersed)-14000 ( 15400(fluid immersed)-30800) |
7000(fluid
immersed)-14000 ( 15400(fluid immersed)-30800) |
| Work
table area (LxW) |
mm
(in) |
500x300
(19 11/16 x11 13/16) |
700x400
(27-9/16x15-3/4) |
600
x 450
(23 5/8 x 17 3/4) |
850
x 450
(33-1/2 x 17-3/4) |
1200
x 700
(41-1/2 x 29-1/2) |
1200
x 750
(47-1/4 x 29-1/2) |
1200
x 750
(47-1/4 x 29-1/2) |
| Travel
( X axis) |
mm
(in) |
300
(11 13/16) |
400
(15-3/4) |
400(15
3/4) |
600(23-5/8) |
800(31-1/2) |
800(31-1/2) |
800(31-1/2) |
| Travel
( Y axis) |
mm
(in) |
200
(7 7/8) |
300
(11-13/16) |
300+100(A.C.E.)
[11 13/16+
3 15/16(A.C.E.)] |
400(15-3/4) |
600(23-5/8) |
1000(39-3/8) |
1200(47-1/4) |
| Machine
head stroke (W axis) |
mm
(in) |
200
(7 7/8) |
200(7-7/8) |
-- |
-- |
-- |
-- |
-- |
Quill
stroke
(Z axis) |
mm
(in) |
200
(7 7/8) |
200
(7-7/8) |
300(11
13/16) |
300(11-13/16) |
250(9-13/16) |
500(19-11/16) |
500(19-11/16) |
| Max.
electrode load |
mm
(in) |
60
(132) |
60(132) |
85(187) |
85(187) |
85(87) |
500(1100)
(Still available for heavier weight by counter weight) |
500(1100)
(Still available for heavier weight by counter weight) |
Machine
installation dimension (including generator)
(W x D x H) |
mm
(in) |
2050
x 1320 x 2080
(80 11/16x 51 15/16x 81 7/8) |
1520x
1470 x 2060
(59-13/1"x57-
7/8x81-1/8) |
1990x
2040 x 2450
(78 5/16x 80 5/16x 96 1/2) |
2470x
1990x 2480
(97-1/4 x 78-5/16 x 97-5/8) |
3920x
3250x 2730
(154-3/8 x 128 x 107-1/2) |
2300x
2800x4090
(90-1/2 x110-1/4 x 161) |
2300x
2800x4090
(90-1/2 x110-1/4 x 161) |
| Machine
weight |
kgs
(lbs) |
1800
(3960) |
1500
(3300) |
2300(5060) |
2400
(5290) |
3600
(7920) |
 10000(22000) |
10000(22000) |
| Max.
process current |
A |
30(50) |
50
(30,75) |
30(50) |
50
(30,75) |
50
(75,100) |
100(75) |
100(75) |
| Max.
power consumption |
KVA |
4.5(6) |
6(4,9) |
4.5
(6) |
6
(4,9) |
6(9,12) |
12(9) |
12(9) |
