MG-650
Machine specification
| model |
mg-650 |
|
| X axis travel | mm (in) |
600 (23 5/8) |
| Y axis travel | mm (in) |
500 (19 11/16) |
| Z axis travel | mm (in) |
400 (15 3/4) |
| Work area | mm (in) |
400x700 (15 3/4x27 9/16) |
| Max. workpiece size (WxDxH) | mm (in) |
600x500x400 (19 11/16x15 3/4) |
| Distance betweenworking table & spindle nose | mm (in) |
200~600 (7 7/8~23 5/8) |
| Max. tool diameter | mm (in) |
60 (2 5/16) |
| Max. tool diameter | mm (in) |
150 (5 7/8) |
| Spindle speeds | r. p. m. |
2000~2000 |
| Taper of spindle nose | BT |
No.30 |
| Spindle motor | KW (HP) |
1~3(1 1/3~4) |
Machine specification
| model |
mg-650 |
|
| Rapid traverse | m/min (ft/min) |
10 (32.8) |
| Cutting feed rate | m/min (in/min) | 1~8000 (0.04~315) |
| Feed axis motor (X) | KW (HP) | 2 (2 2/3) |
| Feed axis motor (Y) | KW (HP) | 2 (2 2/3) |
| Feed axis motor (Z) | KW (HP) | 2 (2 2/3) |
| No. of tools (ATC) | PCS | 6 |
| Air source | kg/cm2(PSI) | 7 (98) |
| Pump motor | KW (HP) | 0.38(1/2) |
| Power consumption | KVA | 13 |
| Machine dimension (WxDxH) | mm (in) |
2300x1800x2600 (90 1/2x70 7/8x102 3/8) |
| Machine weight (approx.) | kgs (lbs) |
4000 (8800) |
| Manufacture reserves the right to change
and modify the specifications, design, mechanisms,... etc. to improve
the performance of the machine without notice. All the specifications shown above are just for reference. |
CNC UNIT
| Control axis | Controlled axes:3(3-axis simultaneous control) |
| Minimum setting increment: 0.001 mm | |
| Feed | Cutting feed rate:F5 digit designation |
| Rapid traverse override: 0 to 120% | |
| Cutting feed override: 0 to 120% | |
| program storage/edit | Program storage capacity: 302m |
| Number of registerable programs :125 | |
| Program editing | |
| I/O funciton | Reader/puncher interface (RS 232C) |
| High speed remote buffer unit B (NC, binary) | |
| Tool offset functions | tool length & tool dia compensation (32 sets) |
| Coordinate systems | coordinate system selection |
| Operating functions | Mirror image |
| Timer functions | |
| Program functions | Radius designation on arc |
| macro | |
| Maintenance and Other functions | Stored pitch error compensation |
| Backlash Compensation | |
| Display of alarm history |
CNC BRIEF FUNCTION
|
Feed rate override Tangential speed constant control Automatic acceleration/deceleration Dwell Manual hand feed Inch/Metric conversion Decimal point input Spindle speed override Tool length compensation Cutter compensation C Reference point return Label skip Canned cycle Backlash compensation Machine lock Dry run Single block Program protection Self-diagnosis function Mirror image |
Stored pitch error compensation Custom macro A Background editing Program re-start External message Exact stop Tool position offset Stored stroke check function ON/OFF Special canned cycle |
